Layla Sheets and Plates, a top-notch manufacturer and supplier based in Cairo, Egypt, is all about crafting high-quality Stainless Steel 201 Angles. These angles are celebrated for their impressive strength, durability, and affordability. They’re engineered to excel in both structural and decorative uses, especially where corrosion resistance and formability are key. Layla Sheets and Plates prides itself on precision engineering, consistent quality, and timely delivery of Stainless Steel 201 Angles, making them a go-to choice for clients in construction, architecture, and fabrication.
The Stainless Steel 201 Angle is primarily made up of chromium (16–18%), nickel (3.5–5.5%), manganese (5.5–7.5%), and nitrogen, striking a great balance between strength and resistance to corrosion. With a tensile strength ranging from about 520 to 750 MPa and impressive elongation properties, this alloy boasts excellent hardness, ductility, and formability, making it perfect for both cold and hot working processes. Its mechanical characteristics make it a dependable alternative to higher nickel stainless steels.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 201 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Ni | N |
| SS 201 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
| Temper | Tensile Strength | Yield Strength | Elongation | Rockwell | ||
|---|---|---|---|---|---|---|
| KSi | MPa | KSi | MPa | in 2 inches % | ||
| 1/2 Hard | 150 | -1034 | 110 | -758 | 10 | C-32 |
| 1/4 Hard | 125 | -862 | 75 | -517 | 20 | C-25 |
| 3/4 Hard | 175 | -1207 | 135 | -931 | 7 | C-37 |
| Annealed | 95 | -655 | 45 | -310 | 40 | B-90 max. |
| Full Hard | 185 | -1276 | 140 | -965 | 5 | C-41 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 201 | S20100 | 1.4372 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 201 Angle provides excellent corrosion resistance, making it ideal for use in light to medium environments. Lightweight yet durable, it provides high stability and system integrity. Its excellent weldability and formability make it easy to manufacture in a variety of configurations. It has excellent oxidation resistance and works well at high temperatures. Affordable compared to other stainless steel grades, it maintains an attractive look with minimal maintenance. Its versatility allows it to be used in construction, automotive, and industrial applications, providing longevity and value.
| Width (mm) | Thickness (mm) | Width (Inches) | Thickness (Inches) |
|---|---|---|---|
| 20 x 20 | 3 to 5 | 3/4″ | 1/8 to 1/4 |
| 25 x 25 | 3 to 5 | 1″ | 1/8 to 1/4 |
| 30 x 30 | 3 to 5 | 1.1/8 | 1/8 to 1/4 |
| 32 x 32 | 3 to 6 | 1.1/4 | 1/8 to 1/4 |
| 35 x 35 | 3 to 6 | 1.3/8 | 1/8 to 1/4 |
| 38 x 38 | 3 to 6 | 1.1/2 | 1/8 to 1/4 |
| 40 x 40 | 3 to 6 | 1.5/8 | 1/8 to 1/4 |
| 45 x 45 | 3 to 6 | 1.3/4 | 1/8 to 1/4 |
| 50 x 50 | 3 to 6 | 2″ | 1/8 to 1/4 |
| 60 x 60 | 5 to 6 | 2.3/8 | 3/16 to 1/4 |
| 65 x 65 | 5 to 6 | 2.1/2 | 3/16 to 1/4 |
| 70 x 70 | 5 to 6 | 2.3/4 | 3/16 to 1/4 |
| 75 x 75 | 5 to 6 | 3″ | 3/16 to 1/4 |
You’ll find Stainless Steel 201 Angle used in a variety of applications, from architectural frameworks and decorative trims to transportation equipment, kitchen appliances, and structural supports. It holds up well in mildly corrosive environments and is known for its excellent weldability and mechanical strength. Plus, its cost-effectiveness and visual appeal make it a fantastic choice for interior design, construction projects, and machinery manufacturing. The combination of toughness and corrosion resistance ensures that it delivers a long service life and reliable performance across a wide range of industrial and commercial uses.
