Layla Sheets and Plates, a well-respected manufacturer and supplier located in Cairo, Egypt, specializes in high-quality Stainless Steel 310S Angle, crafted to endure extreme temperatures and harsh environments. These angles are produced using cutting-edge techniques and top-notch raw materials, guaranteeing outstanding durability and precise dimensions. The Stainless Steel 310S Angle is known for its remarkable resistance to oxidation and thermal fatigue, making it a perfect choice for heat treatment applications. Layla Sheets and Plates is dedicated to delivering products that adhere to global standards, ensuring reliable performance and a long lifespan even in tough industrial settings.
The composition of Stainless Steel 310S Angle includes iron, 24–26% chromium, and 19–22% nickel, along with a low carbon content that boosts its weldability and resistance to sensitization. It boasts a tensile strength of around 515 MPa and a yield strength close to 205 MPa. This alloy retains excellent mechanical strength, oxidation resistance, and toughness, even at high temperatures, making it suitable for both structural and thermal uses.
Standard : ASTM / ASME A276 / SA276
Angle Size : 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm etc.
Flat Size : 2mm ~ 100mm etc.
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Finish : Hot rolled (HR), Cold rolled (CR), Galvanized etc
| Element | SS 310S |
| C | 0.08 max |
| Mn | 2.0 max |
| Si | 1.00 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 24 – 26 |
| Ni | 19 – 21 |
| Mo | 0.75 max |
| Fe | 53.095 min |
| Element | SS 310S |
| Density | 7.9 g/cm3 |
| Melting Point | 1402 °C (2555 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | – | X8CrNi25-21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Layla Sheets and Plates based in Alexandria, Egypt, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 310S angle offers several advantages, including excellent resistance to high temperature oxidation and corrosion, making it ideal for high temperature environments High strength and durability, time saving long system integrity even under extreme conditions. The alloy is also highly resistant to sulfidation and carburization, which is an advantage in hot, humid environments. The lower carbon content reduces carbide precipitation during welding, resulting in improved weldability. In addition, the stainless steel 310S angle retains excellent mechanical properties at high temperatures, making it suitable for industrial applications such as furnaces, heat exchangers and chemical processors.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless Steel 310S Angle finds its application across various industries, including power generation, petrochemicals, furnace manufacturing, and heat treatment. Its exceptional resistance to high-temperature oxidation makes it ideal for furnace linings, heat exchangers, and burners. Additionally, it’s utilized in cryogenic structures and exhaust systems due to its stability over a broad temperature range. In chemical and refinery settings, it stands up well against acidic and carburizing environments. Plus, its strength and attractive finish make it a great choice for architectural and structural projects that require corrosion-resistant materials.
