Layla Sheets and Plates, based in Cairo, Egypt, is an established manufacturer and supplier of top-quality stainless steel 440C angles that are well–known in the industry for their emphasis on quality. Their products meet internationally–recognized specifications for quality and performance. The stainless steel 440C angles are recognized for their superior hardness, corrosion resistance, and precision engineering and are ideal for demanding industrial applications. Layla Sheets and Plates couples technology with skilled craftsmanship to offer dependable, long–lasting and high-performing, material specifications and finishes for the diverse needs of customers within a variety of industries.
Stainless steel 440C angle is a high-carbon martensitic stainless steel with a composition comprising primarily iron, chromium (16–18%), carbon (0.95–1.20%), manganese, silicon, molybdenum (a trace constituent), and heat–resistant composition. Stainless steel 440C angle has excellent hardness and wear resistance when heat treated. It also has moderate corrosion resistance. Stainless steel 440C angle also demonstrates high tensile and compressive strength, superior edge retention, and good dimensional stability. Stainless steel 440C angle has lower ductility and impact toughness, which performs best hardened and tempered for precision and heavy-duty applications.
| Dimensions | EN, ASME, AISI, BS, JIS, DIN, ASTM, |
|---|---|
| Stainless Steel 440C Round Bar size | Thickness: 2 to 100 milimeter |
| Tolerance | K11, H8, H12, K12, H13, H10, H9, K9, K10, H11, or as per need |
| Stainless Steel 440C Round Bar Form | Round, Rod, T-Bars, Channel Bars, Precision Ground Bars, Flat Bars, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Threaded, Hex (A/F), Rectangle, Half Round Bars, Profiles, Billet, Ingot, Forging, I/H Bars etc. |
| Flat bar size | Dia: 3-~800 milimeter |
| Width: 10 – 500 milimeter | |
| size of Stainless Steel 440C Angle bar | 3 milimeter * 20 milimeter* 20 milimeter~12 milimeter* 100 milimeter* 100 milimeter |
| Section bar | 3.0 – 12.0 milimeter thk |
| SS 440C Channel Bar sizes | 5 – 6 milimeter thk, 80 x 40 milimeter – 150 x 75 milimeter section |
| Hollow Bar sizes | 32 milimeter Outside Diameter x 16 milimeter Inside Diameter to 250 milimeter Outside Diameter x 200 milimeter Inside Diameter) |
| Size of Rectangles | 34 x 30 milimeter – 295 x 1066 milimeter |
| Stainless Steel 440C Billet Size | 1/2 – 495 milimeter Diameter |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Finish | Cold (bright) drawn, hot rolled, slit rolled edge, Polish, Bright, peeled, hot rolled annealed, Rough Turned, centreless ground, Centreless Ground, smooth turned, Grinding & Black |
| Technique | Stainless Steel Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Stainless Steel 440C Round Bar Condition | annealed, tempered, Hardened |
| Processing | cutting to 650 milimeter |
|
Stainless Steel 440C |
Max |
Min |
|---|---|---|
|
C |
1.20 |
0.95 |
|
Si |
1.00 |
– |
|
Mn |
1.00 |
– |
|
Ni |
1.00 |
– |
|
Cr |
18.00 |
16.00 |
|
Mo |
0.75 |
0.00 |
|
P |
0.04 |
– |
|
S |
0.03 |
0.15 |
|
Element |
Stainless Steel 440C |
|---|---|
|
Temp°C |
20 |
|
Tensile (UTS)N/mm² |
1965 |
|
0.2% YieldN/mm² |
1896 |
|
Elongation(50.8mm) %) |
2 |
|
HardnessHRc |
57 |
|
Reductionof Area |
10 |
|
STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
|---|---|---|---|
|
Stainless Steel 440C |
1.4125 |
S44004 |
SUS 440C |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Layla Sheets and Plates based in Alexandria, Egypt, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 440C angle offers several advantages including high hardness and excellent wear resistance, making it ideal for heavy load and abrasion applications especially in sensitive corrosive And corrosion environments high resistance, due to its high chromium content. The ability to retain energy at high temperatures makes it suitable for high temperature applications. The material is also very durable, making it last longer and less maintenance. Stainless steel 440C angle is commonly used in the manufacture of tool, machine parts and high performance valves. Its strength and durability make it highly reliable in harsh industrial environments.
Stainless steel 440C angles are used in applications that require high strength, wear resistance, and dimensional accuracy. This product specification is ideal for use in manufacturing bearings, valves, pump shafts and precision instruments. Applications of 440C angles within the aerospace, automotive and tooling industries are common across multiple forms of processing. Layla Sheets and Plates stainless steel 440C angles are a dependable material specification for versatile use across several industries.
