Layla Sheets and Plates, a well-respected manufacturer and supplier located in Cairo, Egypt, specializes in top-notch Stainless Steel 304 Angle that’s built for strength, corrosion resistance, and long-lasting performance. These angles are produced using cutting-edge manufacturing techniques to guarantee exceptional dimensional accuracy and finish. Stainless Steel 304 Angle is one of the most adaptable and commonly used stainless steel products, thanks to its impressive mechanical and chemical properties. Layla Sheets and Plates delivers dependable materials that adhere to international standards, catering to a diverse array of industrial, architectural, and structural needs throughout Egypt and beyond.
Stainless Steel 304 Angle is composed of 18–20% chromium, 8–10.5% nickel, and a maximum of 0.08% carbon. This unique blend offers remarkable corrosion resistance, good formability, and excellent weldability. The alloy boasts a tensile strength of approximately 515 MPa and a yield strength of around 205 MPa, ensuring durability and stability in various environmental conditions. It also exhibits outstanding oxidation resistance and toughness, even in low temperatures.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 304 Angle provides excellent corrosion resistance, making it ideal for harsh environments including coastal areas and industrial conditions Its high strength-to-weight ratio ensures durability and structure of the integrity without excessive quantity. This alloy is easy to fabricate, weld and machine, making it versatile. The material also offers excellent resistance to oxidation and staining, making it suitable for both indoor and outdoor use. Furthermore, the stainless steel 304 Angle is resistant to many chemicals and has high purity, making it attractive to the food and pharmaceutical industries.
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
You’ll find Stainless Steel 304 Angle widely utilized in sectors like construction, chemical processing, food and beverage, and marine engineering. It’s perfect for applications such as frames, supports, railings, and structural reinforcements due to its strength and rust resistance. Moreover, it’s used in equipment for food processing, pharmaceuticals, and architectural projects that demand both hygienic and visually appealing finishes. The blend of corrosion resistance, workability, and mechanical strength makes it a go-to material for both industrial and decorative uses.
