Layla Sheets & Plates is a trusted manufacturer and supplier based in Alexandria, Egypt, specializing in high quality paper plates for a variety of industrial applications Renowned for the accuracy and reliability of their products meet high standards of performance and durability. Additionally, they offer Stainless Steel 321 Angles, a versatile material ideal for high-temperature environments. This stainless steel is resistant to oxidation and corrosion, making it perfect for use in harsh conditions, as well as durability and durability.
Stainless Steel 321 Angle is composed mainly of iron, chromium (17-19%), nickel (9-12%), and titanium (0.5%). It provides good oxidation and corrosion resistance, especially in high-temperature environments due to the inclusion of titanium, which stabilizes the alloy against carbide precipitation Its mechanical properties include high tensile strength (up to 505 MPa ), good ductility and resistance to stress corrosion cracking . The advantages of the stainless steel 321 angle include excellent weldability, excellent creep resistance and stability in harsh environments, making it ideal for use in heat exchangers, reactors and aerospace components.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Layla Sheets and Plates based in Alexandria, Egypt, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 321 angle provides excellent corrosion resistance, especially against high temperatures and acidic environments, making it ideal for applications in industries such as aerospace, chemical processing and automotive It has weldability excellent properties, formability and strength, ensuring durability and structural integrity in critical applications . The addition of titanium increases the stability of the alloy, prevents carbide precipitation during welding, increases its performance in high temperature environments This stainless steel also provides excellent resistance to scaling and oxidation , ensures long-term reliability and minimal maintenance under extreme conditions Its versatile nature in construction engineering . of applications Makes it suitable for a wide range of applications.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless Steel 321 Angle is widely used in applications requiring high thermal resistance and excellent corrosion resistance. This surface is ideal for use in chemical processing, heat exchangers, and high-temperature duct systems due to its stability against intergranular corrosion and is commonly used in aerospace applications, furnace parts, and in thermal oxidizers. SS 321 corners are used in food processing, chemical plants and construction sites for their high strength, weldability and aesthetic appeal Their durability makes them suitable for all construction and decorative purposes.
