Layla Sheets and Plates is a reputable manufacturer and supplier located in Cairo, Egypt, specializing in top-notch Stainless Steel 348 Angle that’s built to perform exceptionally well in high-temperature and corrosive settings. This particular grade of stabilized austenitic stainless steel is celebrated for its remarkable resistance to intergranular corrosion and oxidation. At Layla Sheets and Plates, we leverage cutting-edge manufacturing technology, premium materials, and rigorous quality standards to guarantee that our products are reliable and durable. The Stainless Steel 348 Angle is perfect for industrial and structural applications that require strength, stability, and a long lifespan even in elevated temperature conditions.
The composition of Stainless Steel 348 Angle primarily includes iron, along with 17–19% chromium, 9–13% nickel, and trace amounts of columbium (niobium) and tantalum for stabilization. This unique blend helps prevent carbide precipitation and boosts high-temperature strength. It boasts a tensile strength ranging from about 515–700 MPa and retains excellent mechanical properties, even when exposed to prolonged heat. The alloy is known for its outstanding resistance to oxidation and corrosion, as well as good weldability and toughness, making it a great choice for high-stress and high-temperature applications.
Standard – ASTM A240 / ASME SA240, JIS4304-2005, ASTM A167, EN10088-2-2005, GB/T3280-2007, etc
Thickness – 0.3mm – 100mm
Width – 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc
Length – 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc
Surface – 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Material – Soft, Deep Draw, Extra Deep Draw, Quarter Hard, Half Hard, Full Hard.
Finish – Hot rolled plate (HR), Cold rolled sheet (CR), NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA
Form – Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange), etc.
| Grade | Mn | P | C | S | Cr | Si | Ni | Fe | Co |
| SS 348 | 2.0 | 0.045 | 0.080 | 0.030 | 19 | 1.0 | 11 | 66 | 0.2 |
| SS 348H | 2.00 | 0.045 | 0.04-0.10 | 0.030 | 17.00-19.00 | 0.75 | 9.00-13.00 | – | – |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Rockwell B (HR B) max | Brinell (HB) max |
| 348 | 515 | 205 | 40 | 92/95 | 201/217 |
| 348H | 968 (≥) | 423 (≥) | 32 | 34 | 212 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 348 | 1.4550 | S34800 |
| SS 348H | 1.4961 | S34809 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Layla Sheets and Plates based in Alexandria, Egypt, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 348 angle offers several advantages, including excellent corrosion resistance, especially in high-temperature environments, making it ideal for applications in the chemical, aerospace and petrochemical industries Demonstrates weldability and excellent formability ate, making it easy to manufacture. Intergranular corrosion resistance of the alloy ensures its durability in high temperature applications. Stainless steel 348 also retains its strength at elevated temperatures, making it suitable for use in electric motors and boilers. It is resistant to scaling and oxidation, providing long-term performance under harsh conditions. These qualities ensure reliability and durability.
You’ll find Stainless Steel 348 Angle widely utilized across various industries, including power generation, chemical processing, petrochemical, and aerospace. It’s particularly suited for components like heat exchangers, furnace parts, exhaust systems, pressure vessels, and boiler tubes. Thanks to its stability at high temperatures and resistance to intergranular corrosion, it’s ideal for continuous use in oxidizing environments. Moreover, Stainless Steel 348 Angle is also employed in structural and fabrication projects where durability, strength, and corrosion resistance are essential, ensuring long-lasting reliability and consistent performance even in the toughest conditions.
